We do ventilation And we do it well.
Our range of commercial kitchen canopies are designed to your specific requirements and manufactured .With lead times from 24 hours, we offer the best solution on the market.
Why Green Crystal Canopies?
The primary function of a high-quality canopy is to ensure the efficient removal of contaminated cooking effluent from the kitchen environment.
Conventional exhaust-only canopies often necessitate a substantial volume of exhaust air to function optimally, consequently leading to an increased demand for makeup air and elevated energy expenses. At Green Crystal, our foremost commitment is to safeguard both indoor and outdoor environments. This commitment has driven the development of our cutting-edge Canopy Containment Air (CCA) technology. It is essential to note that when we extract air from the workspace, it must be replaced. Operating in an excessively hot and humid environment is undesirable for anyone, and research has indicated that prolonged exposure to such conditions can lead to higher accident rates and adverse impacts on individual performance.
Canopy Containment Air (CCA)
Crafted with a specific focus on curbing the dissemination of fumes and heat within the workplace, our CCA (Canopy Containment Air) technology ensures that Green Crystal canopies remain highly efficient, sustainable, and consistently cost-effective. This technology operates by releasing a controlled, low-volume, and medium-velocity air stream precisely directed from the leading edge of the hood toward the exhaust filters, resulting in a controlled negative pressure effect along the front lower edge of the canopy.
The design of our CCA technology offers two distinct advantages. Firstly, it establishes an effective containment barrier that confines any potential spillage. Secondly, the negative pressure created actively draws the exhaust plume towards the filters, rendering it the most efficient solution available in the market. This enhanced efficiency translates into a reduction in the overall volume of exhaust and makeup air required, ultimately leading to decreased energy consumption on your part.
Grease Filtration
A canopy’s true worth lies in its ability to deliver exceptional grease and particle filtration. Green Crystal sets a remarkable standard with filtration efficiency reaching up to an impressive 92% for particles exceeding 7 microns in size. We proudly offer one of the foremost fractional primary filtration systems available.
Depending on your specific cooking requirements, we provide a choice of two primary filters. First, our distinctive three-chamber NVX filter utilizes three counter-rotating vortices to effectively eliminate substantial grease and particulate matter before it reaches the ductwork. Alternatively, for applications with lower to medium levels of grease, we offer our NVB ‘baffle’ filter, designed to deliver optimal performance.
LED Specification
Low energy LED lighting shall be inbuilt into the canopy as standard. The LED light fixture shall provide in excess of 500 lux directly to the work surface. The lamps have a nominal average lifetime of 62,000 hours and deliver a warm white light for accurate reflection of the food. A reflective lamp casing shall enhance efficiency and distribution of light. The light fitting is secured within a stainless steel hinged access hatch. This hatch opens to provide easy, safe and convenient maintenance access above the canopy. All edges shall be fully-gasketed and watertight.
Depending on your specific cooking requirements, we provide a choice of two primary filters. First, our distinctive three-chamber NVX filter utilizes three counter-rotating vortices to effectively eliminate substantial grease and particulate matter before it reaches the ductwork. Alternatively, for applications with lower to medium levels of grease, we offer our NVB ‘baffle’ filter, designed to deliver optimal performance.
